Sterrad NX ALLClear
Rapid turnaround in a compact low temperature sterilizer
ASP’s compact size sterilizer STERRAD® NX ALLClear™ Technology has the ability to minimize workflow interruptions before they occur. It is the only sterilization platform with integrated quality control features, which may enhance compliance*. Its unique features include:
- Reduce workflow interruptions
- Automatic pre-cycle detects and removes moisture before start of the sterilization cycle
- Enhance compliance by greater adherence to device IFUs and improved record handling.
- Automatic communication of information between the STERRAD® System, ASP ACCESS™ Technology, and an instrument tracking system or hospital network
- Fully compatible with the Independent Monitoring System (IMS) with sensors that allows for parametric release of instrument loads
- Designed with simplicity in mind to reduce the potential for human error
- Enhanced user interface makes cycle navigation intuitive and straightforward
- Graphic display indicating proper load placement for the selected cycle
- Automated cassette insertion mechanism
- Upgradable and expandable sterilization system
- Trusted and proven worldwide sterility
- Increased healthcare worker safety**
- Reduced costs for instrument repairing; less water and energy consumption**
- Space-efficient system
- Can be easily cart-mounted and moved where needed anywhere in the hospital
- Reduced workflow interruptions.
- Enhanced compliance by greater adherence to device IFUs and improved record handling.
- Designed with simplicity in mind to reduce the potential for human error.
- Upgradable and expandable sterilization system.
- Trusted and proven worldwide sterility.
- Increased healthcare worker safety.
- Reduced costs for instrument repairing; less water and energy consumption.
- Fully compatible with the Independent Monitoring Systems (IMS) for parametric release
- Space-efficient system
STERRAD® NX ALLClear System Specifications
Cycle Specifications* | ||||
Cycles | Standard: sterilizes most general surgical instruments Advanced: sterilizes single-channel rigid endoscopes or up to 1 single-channel flexible endoscope |
|||
Time | Standard: 28 minutes Advanced: 38 minutes | |||
Lumen claims | Standard: single-channel stainless steel lumens diameter: ≥1 mm; length: ≤150 mm OR diameter: ≥2 mm; length: ≤400 mm Advanced: single-channel stainless steel lumens diameter: ≥1 mm; length: ≤500 mm OR single-channel PE/PTFE flexible endoscopes diameter: ≥1 mm; length: ≤850 mm |
|||
Technical Specifications | ||||
Cycle temperature | 47°C–56°C | |||
Sterilant | Hydrogen peroxide | |||
Sterilant delivery | Delivered in closed system in cassettes with automatic detection of expiration date: Standard/Advanced: 3.6 mL per cycle (double kill) (2 ampules, each ampule is 1.8 mL) |
|||
Used cassette disposal | Automatic and touchless ejection into cassette disposal container | |||
Peroxide residual breakdown | Gas plasma technology breaks down H2O2 to safe elements of water and oxygen | |||
Configurations | Single door | |||
System dimensions (maximum) | System Height: 930 mm Width: 554 mm Depth: 792 mm System + Cart Height: 1673 mm Width: 576 mm Depth: 792 mm |
|||
Chamber total volume | 51.3 L | |||
Chamber dimensions | System Height: 230.1 mm Width: 370.1 mm Depth: 660.9 mm | |||
Chamber shape | Rectangular | |||
Shelf info | Two-tiered shelf: Width: 312.8 mm Depth: 600.3 mm | |||
Mobility (Cart) | 4 casters (all locking) | |||
System weight | System: 127.2 kg Cart: 65.3 kg | |||
User interface | Touchscreen technology: projected capacitive touch Resolution: 800 x 600 pixels | |||
Accessory devices | • Barcode reader • External drives: USB that allows data upload and download | |||
Standards/Compliance | ISO 14937 | |||
Sterilization Specifications | ||||
Sterilization process | Terminal-sterilization, double-kill cycle to provide a Sterility Assurance Level (SAL) of 10-6; 2 injections and identical plasma phases | |||
Delivered sterilant concentration | 58%–59.5% | |||
Sterilization cycle monitoring | Critical system parameters monitored with on-board sensors, biological indicators, chemical indicators, IMS (independent monitoring system) available | |||
H2O2 concentration continuous monitoring | Monitoring using UV sensor within the chamber | |||
Installation and Electrical Requirements | ||||
Heat generation | Maximum: 1012 BTU/hour | |||
Electrical power specifications | One dedicated single phase 50/60 Hz, voltage +/- 10%, 2+ ground outlet per the following countries: • US/Canada: 120 VAC, 16A (recommended receptacle: NEMA 5-20R) • Japan: 200 VAC, 10A • International: 200-240 VAC, 10A; 110-120 VAC, 16A |
|||
Service space and installation requirements (Space can be reduced if the system can be moved for servicing.) | Top: 610 mm minimum Left side: • Table installed: 60 mm minimum from sterilizer side • Cart installed: 100 mm minimum from cart side Right side: • Table installed: 610 mm minimum from sterilizer side (Objects placed within this region must be moved during service. Area can be divided up into space on left and right sides.) • Cart installed: 100 mm minimum from cart side Back side: 25.4 mm minimum Front: 1000 mm minimum from front of sterilizer |
|||
Countertop/table specifications | Structure must be able to support a minimum of 182 kg, and have a minimum depth of 584 mm | |||
Operational Environment | ||||
Temperature | 18°C–35°C | |||
Humidity | 10%–85% RH (noncondensing) | |||
Networking and Data Recording | ||||
System performance data and reports | Cycle history, full 1-second data files, and reports available via ASP ACCESS™ Technology | |||
Network connectivity | Communication protocol for Instrument Tracking Systems (ITS) available via ASP ACCESS™ Technology | |||
Data recording | • Electronic data storage up to 50 cycles • Internal printer for manual recordkeeping • Full electronic cycle data and reports via ASP ACCESS™ Technology |
|||
System Ordering Information | ||||
Code | Product Description | |||
10033-004 | STERRAD NX® Sterilization System with ALLClear™ Technology, STANDARD & ADVANCED cycles, includes installation | |||
10311 | STERRAD NX® Sterilization System with ALLClear™ Technology Cart | |||
10133 | STERRAD NX® System Cassette (5 cassettes/case) | |||
113617-01 | STERRAD® Systems Bar Code Scanner Kit | |||
10306 | Cassette disposal box | |||
10305 | Thermal printer paper |
